| Technical Specification |
| System |
| Main Processor |
Embedded Processor |
| Operating System |
Embedded LINUX |
| Display |
| Interface |
1 HDMI ,1 VGA,1 TV |
| Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
| Multi-screen Display |
1/4/8/9/16/25 |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Video Detection and Alarm |
| Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering |
| Alarm input |
N/A |
| Relay Output |
N/A |
| Playback and Backup |
| Playback |
1/4/9/16 |
| Search Mode |
Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device/Network |
| Storage |
| Internal HDD |
2 SATA Ports, up to 8TB capacity for each disk |
| eSATA |
N/A |
| Auxiliary Interface |
| USB |
2 USB Ports (1 USB 3.0,1 USB 2.0) |
| RS232 |
N/A |
| RS485 |
1 Port, for PTZ Control |
| Third-party Support |
| Third-party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
